Reynaers CP 68
Elegance, Comfort and Security
Air tightness max. test pressure4 (600 Pa)
Water tightness 7B (300 Pa)
Wind load resistance C4 (1600 Pa)
Acoustic performanceRw (C; Ctr) = 31 (-1;-5) dB / 38 (-2;-5) dB, depending on glazing type dB
Visible width meeting section 34 mm
Max. height vent 2500 mm
Max. width vent 1500 mm
Max. weight vent (element ) 200 kg
Min. Glass thickness 28 mm
Max. Glass thickness 36 mm
Concept Patio® 68 is a highly-insulated sliding system that combines elegance with performance and security. This unique sliding system is characterised by its slim profiles, allowing the integration of large windows and doors for maximum views, in combination with burglary resistance class RC2. The integrated innovative technologies guarantee ultimate performances with regard to wind and water tightness and thermal insulation, meeting with the highest standards. The sliding system CP 68 offers you all design freedom to create contemporary living spaces, combining ultimate brightness with maximum comfort and security.
